Chili dryer
Drying cycle: 4~8 hours
Operating temperature: 40~80℃
Matching heat source: combustion type, energy type, power consumption type, water heat type
Net belt type pepper dryer adopts strengthened circulation air system, drying of pepper, high degree of automation, no need to be taken care of, temperature and humidity according to the drying process of pepper self-regulation, in order to ensure the natural color, nutrition components are not damaged under the premise of a relatively short time to dry the pepper, dried pepper quality, not broken, good color.
Dear [Chili dryer] customer, it is very lucky that you can find us in the vast information! JUSUNG is a Chili dryer product supply enterprise. Since its establishment, it has been deeply engaged in the Food, Metallurgy, Chemical industry, Textile, Agriculture and Animal husbandry field,to provide Chili dryer products for Food, Metallurgy, Chemical industry, Textile, Agriculture and Animal husbandry customers! We look forward to working with you to create a better future. The following is the relevant information of Chili dryer product organized by JUSUNG for you.
Product advantage of Chili dryer
1. Large output: The dryer adopts multi-layer cyclic dynamic drying mode, which can be processed 24 hours by mass drying.
2. High quality: the dried pepper has bright color, complete shape, strong spicy flavor and moderate moisture, which is trusted by users.
3. Intelligent and accurate: The use of intelligent control system can ensure the temperature, time, air volume and other parameters control in the drying process.
4. cost saving: only one person can complete the whole equipment, drying time is also shortened, saving labor and time cost.
5. High heat energy conversion rate: Independently developed heat exchange device, which can be matched with various heat sources, the heat energy conversion rate is as high as 95%.
6. clean health: the whole drying process is completed in the closed box, will not be polluted by the outside world.
7. long equipment life: the overall running speed of the dryer is very slow, almost no wearing parts, in normal use, the service life is as long as ten to fifteen years or more.
Technical parameter of Chili dryer
|
Dryer model number |
Spreading area |
Handling capacity |
Total power |
Floor area (length * width * height) |
|
2 x 6 meters x 4 layers |
40㎡ |
3tons |
15kw |
20*5*3.5meters |
|
2 x 8 meters x 4 layers |
56㎡ |
5tons |
23kw |
22*5*3.5meters |
|
2 x 10 meters x 4 layers |
72㎡ |
7tons |
28kw |
26*5*3.5meters |
|
2 x 12 meters x 4 layers |
88㎡ |
9tons |
37kw |
28*5*3.5meters |
|
2 x 15 meters x 4 layers |
112㎡ |
12tons |
64kw |
31*5*3.5meters |
|
2 x 20 meters x 4 layers |
152㎡ |
15tons |
86kw |
36*5*3.5meters |
|
2.5 x 12 meters x 6 layers |
165㎡ |
16tons |
55kw |
30*6*3.5meters |
|
2.5 x 15 meters x 6 layers |
210㎡ |
18tons |
75kw |
33*6*3.5meters |
|
2.5 x 20 meters x 6 layers |
285㎡ |
22tons |
103kw |
38*6*3.5meters |
|
2.5 x 25 meters x 6 layers |
360㎡ |
25tons |
108kw |
43*6*3.5meters |
|
2.5 x 30 meters x 6 layers |
435㎡ |
30tons |
130kw |
48*6*3.5meters |
|
Note: Coal or biomass is used as heat source, and chili is used as raw material. |
||||
Strive for excellence,Combat inefficiencies and slow-downs. Brand achievement is not the pursuit of JUSUNG. How to make JUSUNG [Chili dryer] create economic value and serve International social development is the direction that JUSUNG are committed to pursuing!
We combine customer insight with strength in design expertise and leadership to simplify or meet the needs of the markets and brands we serve.
